APF-5

Automatic blow molding machine for PET bottles with volume 3.0-10.0l and output 1 600 bph. Two independent blowing units to produce 2 bottle formats by turns. CE certificate and conformity to HACCP.

APF-5
Equipment type Automatic
Bottle Volume, l 3 - 6, 7 - 10
Output, bph up to 1 600 bph
Your product Water and CSD, Oil and vinegar

Unique features

Full complex for large bottles up to 10l production in automatic mode.

All the machines meet norms and directives of the European quality standard CE and HACCP requirements for food industry, have certificates of conformity to CIS countries standards.

Separate original block of valves for each blowing station designed by PET Technologies R&D department

Technical data



Output 1 600 bph with volume of 3-8 l

up to 1 200 bph with volume of 10 l

Bottle volume 3,0 – 10,0 l
Blowing pressure 8-10 bar
Low pressure up to 30 bar
Low and high pressure air demand 5,0m³/min
Cooling liquid temperature 7-9 °С
Voltage supply 400 V / 50 Hz
Installed power 46 kW
Overall dimensions 7400 х 3200 х 2720 mm
Weight ~ 4 600 kg
preform 67-85 gramms
